Type

Nr.

d₁

d₃

d₄

d₆

b₁

b₃

h

l

l₃

α

weight

n_max

C

C₀

mm

mm

mm

mm

mm

mm

mm

mm

mm

[°]

[kg]

[min^-1]

[N]

[N]

BRO

6

6

M 6

9

20

9

6.75

36

22

12

8.0

0.019

1350

2750

650

BRO

8

8

M 8

10.5

24

12

9

42

25

15

8.5

0.036

1300

4000

1000

BRO

10

10

M 10

12

28

14

10.5

48

29

15

8.0

0.060

1225

4450

1450

BRO

12

12

M 12

14.5

32

16

12

54

33

19

7.5

0.087

1125

4950

1800

BRO

14

14

M 14

17

36

19

13.5

60

36

20

6.0

0.135

1025

5600

2000

BRO

16

16

M 16

19

42

21

15

66

40

22

8.0

0.190

975

6250

2350

BRO

18

18

M 18 x 1.5

21.5

46

23

16.5

72

44

25

8.5

0.270

900

7100

2900

BRO

20

20

M 20 x 1,5

24.5

50

25

18

78

47

28

7

0.338

825

7900

3450

BRO

22

22

M 22 x 1.5

26

54

28

20

84

51

26

8.0

0.450

725

9300

3980

BRO

25

25

M 24 x 2

29.5

64

31

22

94

57

30

5

0.602

600

11030

5680

BRO

30

30

M 30 x 2

34.5

70

37

25

110

66

35

7.5

0.922

450

14150

7450
