产品展示 / Product

3780/3720轴承、KHM807046/KHM807010轴承、28584/28521轴承、K33891/K33822轴承、K33895/K33822轴承、KHM911242/KHM911210轴承、28680/28622轴承、K3979/K3920轴承、K39581/K39520轴承、28985/28921轴承、28985/28920轴承、K392/K392029586/29520轴承、K3982/K3920轴承、K39585/K39520轴承、KHM212047/KHM212011轴承、559/552A轴承、H414235/H414210轴承、KJM511946/KJM511910轴承、KJM211749/KJM211710轴承、29590/29522轴承、K3984/K3920轴承、K39590/K39520轴承、HM803146/HM803110轴承、KHM202049/KHM212011轴承、KHM212049/KHM212010轴承、482/472轴承、K463/633轴承、H913849/H913810轴承、K33281/K33462轴承、K645/K632轴承、29685/29620轴承、K33287/K33462轴承、KJM714249/KJM714210轴承、42687/42620轴承、K495A/K493轴承、575/572轴承、JM515649/JM515610轴承、K496/K493轴承、27687/27620轴承、K47687/K47620轴承、580/572轴承、K663/K653轴承、K27690/K27620轴承、K498/K492A轴承、KJM716649/KJM716610轴承、K749/K742轴承、K497/K493轴承、K596/K592A轴承
·产品材质：	轴承钢
·产品产地：	山东
·产品价格：	￥.00
·网上报价：	￥.00
·生产厂家：	临清达瑞轴承制造有限公司
·联系人：	王洪旗
·联系电话：	0635-2973480
·公司传真：	0635-2103472
·联系邮件：	daruizc@163.com
·邮政编码：	252665
·公司地址：	山东省临清烟店工业园

详细介绍

基本尺寸 mm						现代号	作用点 Function point	基本额定负荷 kN		极限转速 rpm Speed ratings		重量 Weight
Principal dimension						现代号	作用点 Function point	Basic load ratings		极限转速 rpm Speed ratings		重量 Weight
d		D		T		Designations	a	动dyc	静stc	脂润滑 Grease	油润滑 Oil	Kg
mm	英寸Inch	mm	英寸Inch	mm	英寸Inch	Designations	a	Cr	Cor	脂润滑 Grease	油润滑 Oil	Kg
50.8	2	93.264	3.6718	30.162	1.1875	3780/3720	22	113	158	4000	5000	0.87
50.8	2	104.775	4.125	36.512	1.4375	KHM807046/KHM807010	29	127	192	3500	4500	1.48
52.388	2.0625	92.075	3.625	24.608	0.9688	28584/28521	18	78.5	119	3500	4500	0.678
52.388	2.0625	95.25	3.75	27.783	1.0938	K33891/K33822	20	99	140	3000	4000	0.811
53.975	2.125	95.25	3.75	27.783	1.0938	K33895/K33822	20	99	140	3000	4000	0.819
53.975	2.125	130.175	5.125	36.512	1.4375	KHM911242/KHM911210	41	160	210	3000	4000	2.24
55.562	2.1875	97.63	3.8437	24.608	0.9688	28680/28622	21	81.5	129	3000	4000	0.76
57.15	2.25	112.712	4.4375	30.162	1.1875	K3979/K3920	24	126	198	3000	4000	1.46
57.15	2.25	112.712	4.4375	30.162	1.1875	K39581/K39520	24	128	201	3000	4000	1.42
60.325	2.375	100	3.937	25.4	1	28985/28921	24	86.6	138	3000	4000	0.812
60.325	2.375	101.6	4	25.4	1	28985/28920	24	86.6	138	3000	4000	0.851
61.912	2.4375	112.712	4.4375	26.967	1.0617	K392/K3920	27	73.5	105	3000	4000	1.06
63.5	2.5	107.95	4.25	25.4	1	29586/29520	18	84	141	3000	4000	0.914
63.5	2.5	112.712	4.4375	30.162	1.1875	K3982/K3920	24	105	170	2900	3900	1.22
63.5	2.5	112.712	4.4375	30.162	1.1875	K39585/K39520	24	128	201	2900	3900	1.27
63.5	2.5	122.238	4.8125	38.1	1.5	KHM212047/KHM212011	24	173	250	2900	3900	1.9
63.5	2.5	123.825	4.875	38.1	1.5	559/552A	29	147	223	2900	3900	1.99
63.5	2.5	136.525	5.375	41.275	1.625	H414235/H414210	30	240	340	2800	3800	1.04
65*		110*		28		KJM511946/KJM511910	24	119	181	2800	3800	1.06
66*		120*		39		KJM211749/KJM211710	27	170	250	2800	3800	1.86
66.675	2.625	107.95	4.25	25.4	1	29590/29522	18	84	141	2800	3800	0.853
66.675	2.625	112.712	4.4375	30.162	1.1875	K3984/K3920	24	105	170	2800	3800	1.17
66.675	2.625	112.712	4.4375	30.162	1.1875	K3994/K3920	24	105	170	2800	3800	1.17
66.675	2.625	112.712	4.4375	30.162	1.1875	K39590/K39520	24	128	201	2800	3800	1.23
66.675	2.625	112.712	4.4375	30.162	1.1875	HM803146/HM803110	26	105	170	2800	3800	0.743
66.675	2.625	122.238	4.8125	38.1	1.5	KHM202049/KHM212011	24	173	250	2800	3800	1.9
66.675	2.625	122.238	4.8125	38.1	1.5	KHM212049/KHM212010	27	210	280	2800	3800	1.9
69.85	2.75	120	4.7244	29.795	1.173	482/472	26	123	188	2800	3800	1.32
69.85	2.75	130.175	5.125	41.275	1.625	K463/633	29	181	271	2600	3600	2.3
69.85	2.75	146.05	5.75	41.275	1.625	H913849/H913810	45	187	240	2600	3600	2.97
71.438	2.8125	117.475	4.625	30.162	1.1875	K33281/K33462	28	107	180	2600	3600	1.24
71.438	2.8125	136.525	5.375	41.275	1.625	K645/K632	33	181	271	2600	3600	2.55
73.025	2.875	112.712	4.4375	25.4	1	29685/29620	25	89	156	2600	3600	0.878
73.025	2.875	117.475	4.625	30.162	1.1875	K33287/K33462	28	107	180	2600	3600	1.21
75*		120*		31		KJM714249/KJM714210	28	116	204	2600	3600	1.28
76.2	3	127	5	30.162	1.1875	42687/42620	27	167	220	2600	3600	1.44
76.2	3	136.525	5.375	30.162	1.1875	K495A/K493	29	122	198	2400	3400	1.82
76.2	3	139.992	5.5115	36.512	1.4375	575/572	32	170	290	2400	3400	2.44
80*		130*		35		JM515649/JM515610	30	159	280	2400	3400	1.82
80.962	3.1875	136.525	5.375	30.162	1.1875	K496/K493	29	122	198	2400	3400	1.75
82.55	3.25	125.412	4.9375	25.4	1	27687/27620	27	127	151	2400	3400	1.1
82.55	3.25	133.35	5.25	33.338	1.3125	K47687/K47620	28	129	218	2400	3400	1.74
82.55	3.25	139.992	5.5115	36.512	1.4375	580/572	31	197	275	2400	3400	2.21
82.55	3.25	146.05	5.75	41.275	1.625	K663/K653	36	241	360	2400	3400	2.87
83.345	3.2813	125.412	4.9375	25.4	1	K27690/K27620	26	91	160	2400	3400	1.08
84.138	3.3125	133.35	5.25	30.162	1.1875	K498/K492A	29	122	198	2400	3400	1.47
85*		130*		30		KJM716649/KJM716610	30	125	216	2400	3400	1.39
85.026	3.3475	150.089	5.909	44.45	1.75	K749/K742	31	240	365	2400	3400	3.22
85.725	3.375	136.525	5.375	30.163	1.1875	K497/K493	29	122	198	2400	3400	1.6
85.725	3.375	152.4	6	39.688	1.5625	K596/K592A	39	167	286	2000	3400	2.92
