产品展示 / Product

KEE275105/K275155轴承、KEE275108/K275155轴承、M255449/M255410轴承、KL357049/KL357010轴承、LM757049/LM757010轴承、EE649239/649310轴承、L183448/L183410轴承、L183449/L183410轴承、LM11749/LM11710轴承、LM11949/LM11910轴承、K09067/K09196轴承、K09074/K09194轴承、M12649/M12610轴承、K2M12649/K2M12610轴承、LM12749/LM12710轴承、L44643/L44610轴承、KM84548/KM84510轴承、K15579X/K15520轴承、L44649/L44610轴承、K15106/K15250X轴承、K02872/K02820轴承、L45449/L45410轴承、K14118/K14283轴承、LM67048/LM67010轴承、K15123/K15245轴承、KM88048/KM88010轴承、KLM48548/KLM48510轴承、KLM48548A/KLM48511A轴承、K14138A/K14274轴承、25877/25821轴承、L68149/L68110轴承、KLM29749/KLM29710轴承、K16150/K16284轴承、K2788/K2720轴承、K3490/K3420轴承、418/414轴承、HM801346X/HM801310轴承、K2789/K2735X轴承、KLM300849/KLM300811轴承、K3384/K3320轴承、KM802048/KM802011轴承、K3585/K3525轴承、K25577/K25523轴承、K25580/K25520轴承、K355X/K352轴承、LM102949/LM102910轴承、25590/25520轴承、K25590/K25523轴承
·产品材质：	轴承钢
·产品产地：	山东
·产品价格：	￥.00
·网上报价：	￥.00
·生产厂家：	临清达瑞轴承制造有限公司
·联系人：	王洪旗
·联系电话：	0635-2973480
·公司传真：	0635-2103472
·联系邮件：	daruizc@163.com
·邮政编码：	252665
·公司地址：	山东省临清烟店工业园

详细介绍

基本尺寸 mm						现代号	作用点 Function point	基本额定负荷 kN		极限转速 rpm Speed ratings		重量 Weight
Principal dimension						现代号	作用点 Function point	Basic load ratings		极限转速 rpm Speed ratings		重量 Weight
d		D		T		Designations	a	动dyc	静stc	脂润滑 Grease	油润滑 Oil	Kg
mm	英寸Inch	mm	英寸Inch	mm	英寸Inch	Designations	a	Cr	Cor	脂润滑 Grease	油润滑 Oil	Kg
266.7	10.5	393.7	15.5	130.175	5.125	KEE275105/K275155	75	700	1400	750	1000	27.8
273.05	10.75	393.7	15.5	130.175	5.125	KEE275108/K275155	75	700	1400	750	1000	26.3
288.925	11.375	406.4	16	77.788	3.0625	M255449/M255410	72	1140	1900	670	900	30.5
304.8	12	393.7	15.5	50.8	2	KL357049/KL357010	64	530	1210	670	900	14.6
304.8	12	406.4	16	63.5	2.5	LM757049/LM757010	79	2000	2800	670	900	21.2
607.72	23.926	787.4	31	93.662	3.6875	EE649239/649310	124	2000	2800	340	450	108
760*	29.9213	889	35	88.9	3.5	L183448/L183410	127	2000	3200	260	360	93.5
762	30	889	35	88.9	3.5	L183449/L183410	127	2000	3200	260	360	91.9
17.462	0.6875	39.878	1.57	13.843	0.545	LM11749/LM11710	9	25.6	28	9000	13000	0.0758
19.05	0.75	45.237	1.781	15.494	0.61	LM11949/LM11910	10	28	32	8500	1200	0.123
19.05	0.75	49.225	1.938	21.209	0.835	K09067/K09196	15	34	37	8500	1200	0.195
19.05	0.75	49.225	1.938	23.02	0.9063	K09074/K09194	16	34	37	8500	1200	0.201
21.43	0.8437	50.005	1.9687	17.526	0.69	M12649/M12610	11	43	55	8000	11000	0.169
21.43	0.8437	50.005	1.9687	17.526	0.69	K2M12649/K2M12610	11	56	72	8000	11000	0.169
22	0.8653	45.237	1.781	15.494	0.61	LM12749/LM12710	13	32.5	40	8000	11000	0.116
25.4	1	50.292	1.98	14.224	0.56	L44643/L44610	11	26.8	34	7500	10000	0.128
25.4	1	57.15	2.25	19.431	0.765	KM84548/KM84510	16	38	49	7500	10000	0.237
26*		57.15	2.25	17.462	0.6875	K15579X/K15520	19	34.5	43.5	7500	10000	0.207
26.988	1.0625	50.292	1.98	14.224	0.56	L44649/L44610	11	26.8	34	7500	10000	0.126
26.988	1.0625	63.5	2.5	20.638	0.8125	K15106/K15250X	15	42	53	7500	10000	0.316
28.575	1.125	73.025	2.875	22.225	0.875	K02872/K02820	19	50	65.5	7000	9000	0.825
29	1.1417	50.292	1.98	14.224	0.56	L45449/L45410	11	26.8	34	7000	9000	0.118
30	1.811	72.085	2.838	22.385	0.8813	K14118/K14283	17	42	55.5	7000	9000	0.202
31.75	1.25	59.131	2.328	15.875	0.625	LM67048/LM67010	13	40	50	6300	8500	0.175
31.75	1.25	62	2.4409	18.161	0.715	K15123/K15245	13	51.5	62	6300	8500	0.242
33.338	1.3125	68.262	2.6875	22.225	0.875	KM88048/KM88010	19	50.9	70.4	6300	8500	0.382
34.925	1.375	65.088	2.5625	18.034	0.71	KLM48548/KLM48510	14	44.5	60	5600	7500	0.26
34.925	1.375	65.088	2.5625	21.082	0.83	KLM48548A/KLM48511A	14	44.5	60	5600	7500	0.291
34.925	1.375	69.012	2.717	19.845	0.7813	K14138A/K14274	14	42	55.5	5600	7500	0.32
34.925	1.375	73.025	2.875	23.812	0.9375	25877/25821	14	65	85	5600	7500	0.475
35*		59.131	2.328	15.875	0.625	L68149/L68110	13	31	36	5600	7500	0.166
38.1	1.5	65.088	2.5625	18.034	0.71	KLM29749/KLM29710	12	40	57	5000	7000	0.237
38.1	1.5	72.238	2.844	20.638	0.8125	K16150/K16284	17	45	61	5000	7000	0.345
38.1	1.5	76.2	3	23.812	0.9375	K2788/K2720	17	82	110	5000	7000	0.507
38.1	1.5	79.375	3.125	29.37	1.1563	K3490/K3420	20	79.1	104	5000	7000	0.653
38.1	1.5	82.55	3.25	29.37	1.1563	HM801346X/HM801310	25	89	127	5000	7000	0.77
38.1	1.5	88.5	3.4843	26.988	1.0625	418/414	18	90.5	113	5000	7000	0.843
39.688	1.5625	73.025	2.875	23.812	0.9375	K2789/K2735X	17	82	110	4500	6000	0.413
41*		68*	2.6772	17.5	0.689	KLM300849/KLM300811	14	46.5	60	4500	6000	0.241
41.275	1.625	73.431	2.891	19.558	0.77	LM501349/LM501310	15	61	73.5	4500	6000	0.353
41.275	1.625	73.431	2.891	21.43	0.8437	KLM501349/KLM501314	17	61	73.5	4500	6000	0.36
41.275	1.625	80.167	3.1562	29.37	1.1563	K3384/K3320	17	88	114	4500	6000	0.63
41.275	1.625	82.55	3.25	26.543	1.045	KM802048/KM802011	23	76.5	105	4500	6000	0.623
41.275	1.625	87.312	3.4375	30.162	1.1875	K3585/K3525	24	117	175	4500	6000	0.861
42.875	1.688	82.931	3.265	26.988	1.0625	K25577/K25523	19	71	101	4500	6000	0.646
44.45	1.75	82.931	3.265	23.812	0.9375	K25580/K25520	18	70	100	4500	6000	0.573
44.45	1.75	90.119	3.548	23	0.9055	K355X/K352	18	65	85	4500	6000	0.668
45.242	1.7812	73.431	2.891	19.558	0.77	LM102949/LM102910	14	47	70	4500	6000	0.318
45.618	1.796	82.931	3.265	23.812	0.9375	25590/25520	18	70	100	4500	6000	0.556
45.618	1.796	82.931	3.265	26.988	1.0625	K25590/K25523	18	70	100	4500	6000	0.589
