轴承型号
No. | 内径
d
mm in | 外径
D
mm in | 宽度
B
mm in | 倒角
rmin
mm | 额定载荷（KN） | 钢球参数 | Dynamic
Cr | Static
Cor | NO. | Size
mm | ssR3
开闭 | 4.763 | .1875 | 12.70 | .5000 | 3.967
4.978 | .1562
.1960 | 0.3 | 0.89 | 0.42 | 6 | 2.381 | | ssR3A | 4.763 | .1875 | 15.875 | .6250 | 4.978 | .1960 | 0.3 | 0.31 | 0.49 | 7 | 2.381 | | ssR168 | 6.35 | .2500 | 9.525 | .3750 | 3.175 | .1250 | 0.1 | 0.27 | 0.14 | | | | ssR188 | 6.35 | .2500 | 12.70 | .5000 | 3.175 | .1250 | 0.15 | 0.83 | 0.37 | 8 | 1.588 | | ssR4 | 6.35 | .2500 | 15.875 | .6250 | 4.978 | .1960 | 0.30 | 1.136 | 0.558 | 8 | 2.381 | ssR4A
开闭 | 6.35 | .2500 | 19.05 | .7500 | 5.556
7.142 | .2188
.2812 | 0.40 | 2.175 | 1.163 | 6 | 3.969 | ssR6
开闭 | 9.525 | .3750 | 22.225 | .8570 | 5.556
7.142 | .2188
.2812 | 0.40 | 2.56 | 1.35 | 7 | 3.969 | ssR8
开闭 | 12.70 | .5000 | 28.575 | 1.1250 | 6.350
7.938 | .2500
.3125 | 0.40 | 3.90 | 2.23 | 8 | 4.763 | | ssR8-7 | 11.113 | .4375 | 28.575 | 1.1250 | 6.35 | .2500 | 0.40 | 3.912 | 2.245 | 8 | 4.763 | ssR10
开闭 | 15.875 | .6250 | 34.925 | 1.3750 | 7.142
8.731 | .2812
.3437 | 0.60 | 4.62 | 2.79 | 10 | 4.763 | ssR12
开闭 | 19.05 | .7500 | 41.275 | 1.6250 | 7.938
11.113 | .3125
.4375 | 0.60 | 7.24 | 4.46 | 9 | 6.350 | | ss99502H | 15.875 | .6250 | 34.925 | 1.3750 | 7.938 | .3125 | 0.80 | 4.61 | 2.77 | 8 | 5.953 | ssR14
开闭 | 22.225 | .8750 | 47.625 | 1.8750 | 9.525
12.70 | .3705
.5000 | 0.60 | 7.74 | 4.96 | | | ssR16
开闭 | 25.4 | 1.0000 | 50.80 | 2.0000 | 9.525
12.70 | .3705
.5000 | 0.60 | 7.74 | 5.16 | | | ssR18
开闭 | 28.575 | 1.1250 | 53.975 | 2.1250 | 9.525
12.70 | .3705
.5000 | 0.60 | 10.18 | 6.19 | | |
|
