Bearing Unit NO. | Shaft Dia d | Dimensions(mm) | Bearing No. | Housing No. | Weight (kg) | |
(in) | (mm) | a | w | h | j | s | g | Bi | n | c | |
UCECH201-8
UCECH202-9
UCECH202-10
UCECH203-11
UCECH204-12
UCECH201
UCECH202
UCECH203
UCECH204 | 1/2
9/16
5/8
11/16
3/4
| 12
15
17
20 | 64 | 96 | 64 | 40 | PF3/4 | 19 | 31 | 12.7 | 0 | UC201-8
UC202-9
UC202-10
UC203-11
UC204-12
UC201
UC202
UC203
UC204 | ECH204 | 0.5 | |
|
|
UCECH205-13
UCECH205-14
UCECH205-15
UCECH205-16
UCECH205 | 13/16
7/8
15/16
1 | 25 | 78 | 103 | 64 | 40 | PF3/4 | 19 | 34 | 14.3 | 0 | UC205-13
UC205-14
UC205-15
UC205-16
UC205 | ECH205 | 0.5 | |
UCECH206-17
UCECH206-18
UCECH206-19
UCECH206-20
UCECH206 | 1-1/16
1-1/8
1-3/16
1-1/4 | 30 | 78 | 103 | 64 | 40 | PF3/4 | 19 | 38.1 | 15.9 | 0 | UC206-17
UC206-18
UC206-19
UC206-20
UC206 | ECH206 | 0.5 | |
UCECH207-20
UCECH207-21
UCECH207-22
UCECH207-23
UCECH207 | 1-1/4
1-5/16
1-3/8
1-7/16 | 35 | 92 | 116 | 70 | 40 | PF3/4 | 19.1 | 42.9 | 17.5 | 0 | UC207-20
UC207-21
UC207-22
UC207-23
UC207 | ECH207 | 0.6 | |
UCECH208-24
UCECH208-25
UCECH208 | 1-1/2
1-9/16 | 40 | 96 | 121 | 73 | 40 | PF3/4 | 19 | 49.2 | 19 | 2 | UC208-24
UC208-25
UC208 | ECH208 | 0.5 | |
UCECH209-26
UCECH209-27
UCECH209-28
UCECH209 | 1-5/8
1-11/16
1-3/4 | 45 | 108 | 136 | 82 | 48 | PF3/4 | 21 | 49.2 | 19 | 5 | UC209-26
UC209-27
UC209-28
UC209 | ECH209 | 1.4 | |
UCECH210-29
UCECH210-30
UCECH210-31
UCECH210-32
UCECH210 | 1-13/16
1-7/8
1-15/16
2 | 50 | 118 | 142 | 83 | 48 | PF1 | 21 | 51.6 | 19 | 5 | UC210-29
UC210-30
UC210-31
UC210-32
UC210 | ECH210 | 1.8 | |
UCECH211-32
UCECH211-33
UCECH211-34
UCECH211-35
UCECH211 | 2
2-1/16
2-1/8
2-3/16 | 55 | 126 | 158 | 95 | 60 | PF1-1/4 | 25 | 55.6 | 22.2 | 7 | UC211-32
UC211-33
UC211-34
UC211-35
UC211 | ECH211 | 1.85 | |
UCECH212-36
UCECH212-37
UCECH212-38
UCECH212-39
UCECH212 | 2-1/4
2-5/16
2-3/8
2-7/16 | 60 | 142 | 173 | 102 | 60 | PF1-1/4 | 28 | 65.1 | 25.4 | 9 | UC212-36
UC212-37
UC212-38
UC212-39
UC212 | ECH212 | 2.87 | |
UCECH213-40
UCECH213-41
UCECH213 | 2-1/2
2-9/16 | 65 | 166 | 200 | 117 | 70 | PF1-1/2 | 32 | 65.1 | 25.4 | 9.5 | UC213-40
UC213-41
UC213 | ECH213 | 4.75 | |
UCECH214-42
UCECH214-43
UCECH214-44
UCECH214 | 2-5/8
2-11/16
2-3/4 | 70 | 166 | 200 | 117 | 70 | PF1-1/2 | 32 | 74.6 | 30.2 | 9.5 | UC214-42
UC214-43
UC214-44
UC214 | ECH214 | 4.75 | |
UCECH215-45
UCECH215-46
UCECH215-47
UCECH215-48
UCECH215 | 2-13/16
2-7/8
2-15/16
3 | 75 | 166 | 200 | 117 | 70 | PF1-1/2 | 32 | 77.8 | 33.2 | 9.5 | UC215-45
UC215-46
UC215-47
UC215-48
UC215 | ECH215 | 4.75 | |
