Bearing Unit NO.

Shaft Dia d

Dimensions(mm)

Bolt Used

Bearing No.

Housing No.

Weight (kg)

(in)

(mm)

a

h

e

j

i

g

l

s

b

f

z

Bi

n

mm

in

UCFB201-8
UCFB202-9
UCFB202-10
UCFB203-11
UCFB204-12
UCFB201
UCFB202
UCFB203
UCFB204

1/2
9/16
5/8
11/16
3/4

12
15
17
20

108

42.9

38.1

22

15.9

8

25.4

10

63.5

60.3

34.1

31

12.7

M8

5/16

UC201-8
UC202-9
UC202-10
UC203-11
UC204-12
UC201
UC202
UC203
UC204

FB204

0.38

UCFB205-13
UCFB205-14
UCFB205-15
UCFB205-16
UCFB205

13/16
7/8
15/16
1

25

121

46

41.3

28.5

16.7

9.5

28.5

10

70

63.5

36.5

34

14.3

M8

5/16

UC205-13
UC205-14
UC205-15
UC205-16
UC205

FB205

0.49

UCFB206-17
UCFB206-18
UCFB206-19
UCFB206-20
UCFB206

1-1/16
1-1/8
1-3/16
1-1/4

30

137

52.4

47.6

31.7

18.6

9.5

32

10

83

70

40.9

38.1

15.9

M8

5/16

UC206-17
UC206-18
UC206-19
UC206-20
UC206

FB206

0.61

UCFB207-20
UCFB207-21
UCFB207-22
UCFB207-23
UCFB207

1-1/4
1-5/16
1-3/8
1-7/16

35

156

60.3

50.8

31.7

21

12.7

36.5

13

95

83

46.4

42.9

17.5

M10

3/8

UC207-20
UC207-21
UC207-22
UC207-23
UC207

FB207

0.75

UCFB208-24
UCFB208-25
UCFB208

1-1/2
1-9/16

40

164

60.3

50

41.3

21

15.9

35.7

12

100

78

51.2

49.2

19

M10

3/8

UC208-24
UC208-25
UC208

FB208

0.8

UCFB209-26
UCFB209-27
UCFB209-28
UCFB209

1-5/8
1-11/16
1-3/4

45

174

65

54

42.9

21.8

18.3

38

12

106

80

51.2

49.2

19

M10

3/8

UC209-26
UC209-27
UC209-28
UC209

FB209

1.5

UCFB210-29
UCFB210-30
UCFB210-31
UCFB210-32
UCFB210

1-13/16
1-7/8
1-15/16
2

50

190

74.6

70

41.3

21.8

12.7

38

13

118

102

53.6

51.6

19

M10

3/8

UC210-29
UC210-30
UC210-31
UC210-32
UC210

FB210

1.8
