Bearing Unit NO.

Shaft Dia
d

Dimensions(mm)

Bolt Used

Bearing
No.

Housing
No.

Weight
(kg)

(in)

(mm)

a

p

e

i

s

j

k

g

f

z

Bi

n

mm

in

UCFCF205-13
UCFCF205-14
UCFCF205-15
UCFCF205-16
UCFCF205

13/16
7/8
15/16
1

25

111

92

65.1

11

10.3

6.4

9.5

22

76.2

30.8

34.1

14.3

M8

5/16

UC205-13
UC205-14
UC205-15
UC205-16
UC205

FCF205

0.99

UCFCF206-17
UCFCF206-18
UCFCF206-19
UCFCF206-20
UCFCF206

1-1/16
1-1/8
1-3/16
1-1/4

30

127

105

74.2

7.5

12

11

9.5

20

85.7

29.7

38.1

15.9

M10

3/8

UC206-17
UC206-18
UC206-19
UC206-20
UC206

FCF206

1.36

UCFCF207-20
UCFCF207-21
UCFCF207-22
UCFCF207-23
UCFCF207

1-1/4
1-5/16
1-3/8
1-7/16

35

133

111

78.5

7.1

12

12

13

22

92

32.5

42.9

17.5

M10

3/8

UC207-20
UC207-21
UC207-22
UC207-23
UC207

FCF207

1.76

UCFCF208-24
UCFCF208-25
UCFCF208

1-1/2
1-9/16

40

133

111

78.5

9.5

12

12

13

26

92

39.7

49.2

19

M10

3/8

UC208-24
UC208-25
UC208

FCF208

1.93

UCFCF209-26
UCFCF209-27
UCFCF209-28
UCFCF209

1-5/8
1-11/16
1-3/4

45

156

130

92

5.6

13.5

12

11.5

22

108

37.6

49.2

19

M12

7/16

UC209-26
UC209-27
UC209-28
UC209

FCF209

2.38

UCFCF210-29
UCFCF210-30
UCFCF210-31
UCFCF210-32
UCFCF210

1-13/16
1-7/8
1-15/16
2

50

162

137

96.5

8.7

13.5

16

13

27

114

41.3

51.6

19

M12

7/16

UC210-29
UC210-30
UC210-31
UC210-32
UC210

FCF210

2.93

UCFCF211-32
UCFCF211-33
UCFCF211-34
UCFCF211-35
UCFCF211

2
2-1/16
2-1/8
2-3/16

55

181

152

108

5.6

15

22.2

13

22.2

127

39

55.6

22.2

M12

7/16

UC211-32
UC211-33
UC211-34
UC211-35
UC211

FCF211

3.67
